Specification Basic Information Supported CPU Supports AMD Ryzen™ 5000 & 3000 Series Desktop Processors And AMD Ryzen™ 4000 G-Series Desktop Processors Chipset AMD A520 Chipset Memory 2x DDR4 Memory Slots, Support Up To 64GB Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz By JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600 MHz By A-XMP OC MODE 1DPC 1R Max Speed 4600 MHz 1DPC 2R Max Speed 3866 MHz Dual Channel Memory Architecture Supports Non-ECC UDIMM Memory Supports ECC UDIMM Memory (Non-ECC Mode) Supports Un-Buffered Memory Graphics 1x HDMI 2.1 Port, Supporting A Maximum Resolution Of 4096×2160 @60Hz12 Support HDCP 1.4 & 2.3 1 X VGA Port, Supporting A Maximum Resolution Of 2048×1280 @60Hz1 Maximum Shared Memory Of 16GB Slots 1x PCIe 3.0 X1 Slot 1x PCIe 3.0 X16 Slot Supported Storage AMD A520 Chipset 4x SATA 6Gb/S Ports 1x M.2 Slot (Key M) (From AMD Processor) Supports PCIe 3.01 Supports SATA 6Gb/S Supports 2242/ 2260/ 2280 Storage Devices LAN 1x Realtek RTL8111H 1Gbps LAN Controller Audio Realtek® ALC892/ ALC897 Codec 7.1-Channel High Definition Audio USB Port AMD A520 Chipset 2x USB 3.2 Gen 1 5Gbps Ports Are Available Through The Internal USB 3.2 Gen 1 5Gbps Connector 6x USB 2.0 Ports (2 Type-A Ports On The Back Panel, 4 Ports Through The Internal USB 2.0 Connectors AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A Ports On The Back Panel Internal I/O Ports 1x 24-Pin ATX Main Power Connector 1x 4-Pin ATX 12V Power Connector 4x SATA 6Gb/S Connectors 1x M.2 Slots (M-Key) 1x USB 3.2 Gen 1 5Gbps Connector (Supports Additional 2 USB 3.2 Gen 1 5Gbps Ports) 2x USB 2.0 Connectors (Supports Additional 4 USB 2.0 Ports) 1x 4-Pin CPU Fan Connector 1x 4-Pin System Fan Connector 1x Front Panel Audio Connector 2x System Panel Connectors 1x Chassis Intrusion Connector 1x TPM Module Connector 1x Clear CMOS Jumper External I/O Ports HDMI VGA Keyboard / Mouse USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 1 5Gbps Type-A LAN Port Audio Connector USB 2.0 Type-A DIMENSIONS 9.3 In. X 7.9 In. (23.6 Cm X 20 Cm) Form Factor MATX Form Factor Warranty 3 Years Description MSI A520M PRO-VH AMD AM4 Micro-ATX Motherboard PRO Series Helps Users Work Smarter By Delivering An Efficient And Productive Experience. Featuring Stable Functionality And High-Quality Assembly, PRO Series Motherboards Provide Not Only Optimized Professional Workflows But Also Less Troubleshooting And Longevity.MSI Motherboards Let You Manage Speeds And Temperatures For All Your System And CPU Fans. Total Fan Control Allows You to Check Your Primary System Characteristics In A Simplified Graphical Interface. You Can Also Set Up To 4 Temperature Targets For CPU And Motherboard, Which Will Adjust The Fan Speeds Automatically. MSI PRO Series Motherboards Support All The Latest Storage Standards, Which Allows Users To Connect to Any Ultra-Fast Storage Device. Higher Efficiency Makes Your Work Easier. An Enhanced PCB Design With 2oz Thickened Copper Increases Conductivity, Improving Heat Dissipation And Performance Reliability Especially During Overclocking. MSI A520M PRO-VH AMD AM4 Micro-ATX Motherboard has 03 years warranty. MSI A520M PRO-VH AMD AM4 Micro-ATX Motherboard Price in BD The Best price for MSI A520M PRO-VH AMD AM4 Micro-ATX Motherboard is 8,300 taka only. You can buy MSI A520M PRO-VH AMD AM4 Micro-ATX Motherboard and also you can visit Our showroom and Join Our Facebook Page.
